The Grail SE
Mains power | available with 115/120Volts or 230Volts, 50/60Hz. |
---|---|
Input | 1* MM, 2* MC; RCA or XLR. |
Max. undistorted output voltage | 15Vss |
Output impedance | 330 Ohms (real resistive), 600 Ohms at balanced out |
Input sensivity values | (given for 250mV RMS resp. 0,707Vss output level on amplifier output) |
Signal to noise | > = 77dB |
Input impedance | autom. matching in milliseconds from appr. 2 Ohms up to 2,000 Ohms |
Size (W x H x L, incl. feet) | 475 x 95 x 335mm |
Weight | 19,5KG (appr. 43lbs) without the ext. power supplies |
Temperature operating range | from 15deg. Celsius up to 30deg. Celsius room temperature. No condensing on item allowed. Use only in dry rooms |
